According to the different media conveyed by the users, the material of the overcurrent components of the pump consists of fluoroplastic, bismuth glass, various austenitic stainless steel, titanium metal, nickel metal, etc.,

so it can be widely used to transport low temperature, normal temperature or high temperature corrosive medium.

And allow a certain amount of solid particles, mainly used in chemical, petrochemical, oil refining, metallurgy, light industry, pharmaceutical and other industrial sectors.

1.Improve the lifespan of mechanical seals and bearings with the highest failur e rate in chemical pump operation.

2. Use thicker shafts to increase shaft stiffness.

3.The bearing is enlarged, and the double-row radial thrust ball bearing is adopted. The axial clearance of the rotor is small, the lifespan of bearing is larger than 25,000 hours, which prolongs the lifespan of the mechanical seal.

4.The impeller and the pump shaft can be connected by screws, the sealing is reliable, the disassembly and assembly is convenient, and the anti-cavitation is better than the IH pumps.

5.Available in a variety of shaft seal types: single-end, double-end, internally mounted, externally mounted mechanical seals, cartridge seals, packing seals, etc., and can be supplied with the mechanical seal auxiliar y system according to the API610 standard.

Material: Carbon steel, ss304, ss316, duplex steel, titanium alloy,  etc.;

Standard: ISO2858;
