This pump is suitable for transporting oil, liquefied gas and other media without solid particles.

Mainly used in:

refinery,

petrochemical industry;

chemical industry and general process industry;

water supply plant,

seawater desalination plant;

power plant;

iron and steel industry;

shipbuilding and offshore industry, etc.

AY type oil pump is a single-suction single-stage and single-suction two-stage cantilever centrifugal pump. The pump body is radially split. The installation method is horizontal center support. The inlet and outlet flanges of the pump body are top-in and top-out.

The front and rear mouth rings and balance holes are used for hydraulic balance. The stuffing box has a cooling or heating jacket, and the shaft seal adopts packing seal. It can also use single-end or double-end mechanical seals, and is equipped with cooling, flushing or sealing fluid systems.

The pipeline system is designed according to API610 specification, which can cool the pump support supported by the center.

Seen from the motor side, the pump rotates counterclockwise.
